MOON Evolution 700i - Chuyên trị những cặp loa khó đánh

The MOON 700i is the ultimate Integrated Amplifier. Intended to meet the needs of the most demanding music connoisseurs, it is fully differential dual-mono design, rated at 175 watts/channel, offering authority, finesse and superb control.

Using a variety of new technologies developed since the introduction of the Evolution Series, the 700i provides more sonic transparency and accuracy than previously thought possible. In addition, this integrated offers extreme flexiblity while exuding a luxurious presence in any environment.



New technologies include (i) the M-eVOL2 volume control, with a phenomenal 530 steps, allowing for an extremely precise level adjustment just like the MOON 850P Preamplifier; (ii) MOON output transistors, specifically designed for use in our amplifiers, provide tighter and more visceral bass performance, as well as unprecedented linearity thoughout the entire frequency spectrum; (iii) An input stage circuit which reduces noise, preserving image focus and integrity like never before.

Of course, key features you'd expect in a MOON Evolution Series product are present such as our "no overall feedback" amplification circuitry, SimLink™ and M-Lock, just to name a few, as well as both RS-232 and IR ports for custom-install environments.

Technical aspects

+ Lynx circuitry which is a "no overall feedback" design resulting in genuine real-time amplification, a more accurate musical reproduction with respect to tonality, virtually non-existent IMD and the elimination of common phase errors resulting from feedback

+ Custom proprietary toroidal transformer design with lower magnetic, electrical and thermal loss, yielding an improved power transfer and lower regulation factor. The result is increased current speed and better dynamics

+ A dual-mono oversized power supply

+ The preamplifier section is mounted on its own dedicated circuit board resulting in lower crosstalk

+ M-eVOL2 volume control circuit using MDAC's (operating in a current steering R-2R configuration) which alter the audio signal's amplitude, yielding no sonic degradation of the signal, regardless of the selected volume setting

+ "Class A" output to 5 watts for greater efficiency

+ M-Lock for "user selectable" maximum volume setting lock-out for each line input

+ "Gain offset" for each individual line input with a ±10dB range

+ Precision matched and fully decoupled proprietary MOON Bipolar output transistors with unprecedented gain linearity resulting in improved bass response and even more accurate sonic reproduction

+ Each line input is fully configurable to be "home-theater ready", where the gain section of the 700i is bypassed

+ RS-232 port for (i) full unsolicited bidirectional feedback and (ii) firmware updates

+ IR input for external control

+ 12 Volt trigger output for remote operation

+ SimLink™ controller port for 2-way communications with other compatible MOON components

+ 4-Layer printed circuit boards with pure copper tracings for a much shorter signal path; This results in greater sonic accuracy and a dramatically improved signal-to-noise ratio

+ Accurate matching of the very finest quality electronic components in a symmetrical circuit design

+ Includes FRM-3 remote control

Link tham khảo:
http://www.nguyenaudio.com/vn/san-p...ier/moon-by-simaudio/moon-evolution-700i.html
Giá tham khảo : 322.000.000 VNĐ

..........................................................................................................................................................................

Call: Mr Thành 0902 91 93 94
Showroom : 231 Điện Biên Phủ , P 6 , Q 3 , TPHCM
.........................................................................................................................................................................
Raidho Acoustics, Aurender, Chord Electronics, Triangle, Paradign, Zu Audio, Norma Audio, JL Audio, KR Audio, Diapasion, Purist Audio, Van Den Hul ...
